Electronic Torque Control Wrench
Features and Benefits
- Simple Torque Setting Procedure
- Simply set target-torque value with torque graduation.
- Simple and Easy Operation
- Wrench shuts off automatically when desired torque is reached
- Accurate Repeated-Torque
- Range within ±5%
- Can Be Operated in Both Directions
- Tightening and loosening
- Low Sound Pressure and Vibration Level
- Does not restrict night time or in a narrow room operation
- Ergonomically Designed Pistol Style Body
- Unique design and light weight derives easy handling, high mobility and less fatigue after consecutive operations.
Specifications | ||||
---|---|---|---|---|
Model | SAM-22E | SAL-24E | SAH-27E | SAV-30E |
Rated Voltage(Single Phase) | 230V~ | 230V~ | 230V~ | 230V~ |
Max. Input Power | 9A | 9A | 9A | 9A |
Max. Power Consumption | 2000W | |||
No-Load Speed | 23 min-1 | 16 min-1 | 9 min-1 | 5 min-1 |
Weight (mainbody) | 5.5 Kg | 6.5 Kg | 6.8 Kg | 8.8 Kg |
Bolt Sockets | M 20 & M22 | M 22 & M29 | M 24 & M27 | M 27 & M30 |
